Technical data
SWING OVER BED |
1230 mm |
SWING CROSS OVER SLIDE |
900 mm |
SWING OVER GAP |
1400 mm |
CENTRE DISTANCE |
1500 mm |
SPINDLE TAPER |
C11/D11 |
SPINDLE BORE |
105 mm/130 mm |
SPINDLE SPEED |
10-800 (18 ranges) |
SUPPORT PASS |
615 mm |
UPPER HOLDER PASS |
225 mm |
QUICK CROSS PASS |
Z axis: 3200, X axis: 1400 mm/min |
SLEEVE DIAMETER |
120 mm |
SLEEVE BORE |
270 mm |
SLEEVE TAPER |
Morse 6 |
BED WIDTH |
610 mm |
METRIC THREADING |
1 - 240 mm |
INCH THREADING |
30 - 2 tpi |
MODULAR THREADING |
0.25 - 60 mm |
DIAMETRAL THREADING |
60-1 tpi |
LONGITUDINAL FEED |
0.07 - 16.72 mm/rotation |
CROSS FEED |
0.04 - 9.6 mm/rotation |
MAIN POWER MOTOR |
11 kW |
DIMENSIONS |
4340 x 1700 x 2080 mm |
WEIGHT |
6500-9600 kg |
Standard equipment
- Four-jaw clamp and flange Φ500 (123C): Φ630 (143C, 163C, 183C)
- Dead centre
- Reduction arbor
- Maintenance kit
- Anchor bolts and nuts
- Levelling block
- Steady rest mechanism (distance between centres not smaller than 3000 mm) / Φ500 (123C), Φ700 (143C, 163C, 183C)
Optional equipment
- Three-jaw clamp and flange
- Face plate
- Steady rest (up to 3000 mm)
- Follow rest
- Spindle bore Φ130
- Electric gun
- Electric sleeve
- Additional element for taper turning
Основні | |
---|---|
Виробник | Cormak |
Країна виробник | Польща |
- Ціна: 2 041 674 ₴
